tsm::freertos_task_executor< Tasks > Class Template Reference

#include <freertos.h>

Collaboration diagram for tsm::freertos_task_executor< Tasks >:

Public Member Functions
	freertos_task_executor (Tasks &... tasks)
	freertos_task_executor (freertos_task_executor const &)=delete
freertos_task_executor &	operator= (freertos_task_executor const &)=delete
	~freertos_task_executor ()
void	start (char const *name="tsm_exec", uint16_t stack_depth=configMINIMAL_STACK_SIZE, UBaseType_t priority=tskIDLE_PRIORITY+1U)
void	stop ()
void	wake ()
void	wake_from_isr ()
void	wait_for_work ()
bool	step ()
std::size_t	run_ready ()
std::size_t	tick (tsm::tick_rep elapsed_ticks=1U)
std::size_t	tick (tsm::tick_count elapsed_ticks)
void	start_all ()
template<auto Entry, std::size_t Instance = 0U>
spawn_result	start ()
template<auto Entry, typename... Args>
spawn_result	spawn (Args &&... args)
runtime::task_spawner< freertos_task_executor >	spawner ()
template<auto Entry, std::size_t Instance = 0U>
task_status	task_status () const
template<auto Entry, std::size_t Instance = 0U>
task_failure_reason	task_failure_reason () const
template<auto Entry, std::size_t Instance = 0U>
bool	cancel () noexcept
void	cancel_all () noexcept

Protected Member Functions
void	run_task ()

Static Protected Member Functions
static void	task_entry (void *pv_parameters)

Protected Attributes
tsm::runtime::cooperative_executor< Tasks... >	ready_
TaskHandle_t	task_handle_ {}
BaseType_t	stop_requested_ { pdTRUE }

Detailed Description

template<typename... Tasks>
class tsm::freertos_task_executor< Tasks >

FreeRTOS task executor.

The executor owns one FreeRTOS task that drains one or more tsm runtimes through the same step / run_ready contract used by the host and bare-metal executors. Runtimes still own their HSMs and queues.

Constructor & Destructor Documentation

freertos_task_executor() [1/2]

template<typename... Tasks>

tsm::freertos_task_executor< Tasks >::freertos_task_executor ( Tasks &...  tasks )

inlineexplicit

freertos_task_executor() [2/2]

template<typename... Tasks>

tsm::freertos_task_executor< Tasks >::freertos_task_executor ( freertos_task_executor< Tasks > const &  )

delete

~freertos_task_executor()

template<typename... Tasks>

tsm::freertos_task_executor< Tasks >::~freertos_task_executor ( )

inline

Member Function Documentation

cancel()

template<typename... Tasks>

template<auto Entry, std::size_t Instance = 0U>

bool tsm::freertos_task_executor< Tasks >::cancel ( )

inlinenoexcept

cancel_all()

template<typename... Tasks>

void tsm::freertos_task_executor< Tasks >::cancel_all ( )

inlinenoexcept

operator=()

template<typename... Tasks>

freertos_task_executor& tsm::freertos_task_executor< Tasks >::operator= ( freertos_task_executor< Tasks > const &  )

delete

run_ready()

template<typename... Tasks>

std::size_t tsm::freertos_task_executor< Tasks >::run_ready ( )

inline

run_task()

template<typename... Tasks>

void tsm::freertos_task_executor< Tasks >::run_task ( )

inlineprotected

spawn()

template<typename... Tasks>

template<auto Entry, typename... Args>

spawn_result tsm::freertos_task_executor< Tasks >::spawn ( Args &&...  args )

inline

spawner()

template<typename... Tasks>

runtime::task_spawner<freertos_task_executor> tsm::freertos_task_executor< Tasks >::spawner ( )

inline

start() [1/2]

template<typename... Tasks>

template<auto Entry, std::size_t Instance = 0U>

spawn_result tsm::freertos_task_executor< Tasks >::start ( )

inline

start() [2/2]

template<typename... Tasks>

void tsm::freertos_task_executor< Tasks >::start ( char const *  name = "tsm_exec", uint16_t  stack_depth = configMINIMAL_STACK_SIZE, UBaseType_t  priority = tskIDLE_PRIORITY + 1U  )

inline

start_all()

template<typename... Tasks>

void tsm::freertos_task_executor< Tasks >::start_all ( )

inline

step()

template<typename... Tasks>

bool tsm::freertos_task_executor< Tasks >::step ( )

inline

stop()

template<typename... Tasks>

void tsm::freertos_task_executor< Tasks >::stop ( )

inline

task_entry()

template<typename... Tasks>

static void tsm::freertos_task_executor< Tasks >::task_entry ( void *  pv_parameters )

inlinestaticprotected

task_failure_reason()

template<typename... Tasks>

template<auto Entry, std::size_t Instance = 0U>

task_failure_reason tsm::freertos_task_executor< Tasks >::task_failure_reason ( ) const

inline

task_status()

template<typename... Tasks>

template<auto Entry, std::size_t Instance = 0U>

task_status tsm::freertos_task_executor< Tasks >::task_status ( ) const

inline

tick() [1/2]

template<typename... Tasks>

std::size_t tsm::freertos_task_executor< Tasks >::tick ( tsm::tick_count  elapsed_ticks )

inline

tick() [2/2]

template<typename... Tasks>

std::size_t tsm::freertos_task_executor< Tasks >::tick ( tsm::tick_rep  elapsed_ticks = 1U )

inline

wait_for_work()

template<typename... Tasks>

void tsm::freertos_task_executor< Tasks >::wait_for_work ( )

inline

wake()

template<typename... Tasks>

void tsm::freertos_task_executor< Tasks >::wake ( )

inline

wake_from_isr()

template<typename... Tasks>

void tsm::freertos_task_executor< Tasks >::wake_from_isr ( )

inline

Member Data Documentation

ready_

template<typename... Tasks>

tsm::runtime::cooperative_executor<Tasks...> tsm::freertos_task_executor< Tasks >::ready_

protected

stop_requested_

template<typename... Tasks>

BaseType_t tsm::freertos_task_executor< Tasks >::stop_requested_ { pdTRUE }

protected

task_handle_

template<typename... Tasks>

TaskHandle_t tsm::freertos_task_executor< Tasks >::task_handle_ {}

protected

---

The documentation for this class was generated from the following file:

• include/tsm/freertos.h
