Target-neutral tick value type. More...
#include <chrono>#include <cstdint>#include <ratio>#include <type_traits>
Include dependency graph for ticks.h:
This graph shows which files directly or indirectly include this file:
Go to the source code of this file.
Classes | |
| struct | tsm::tick_count |
| Strong value type for semantic scheduler ticks. More... | |
Namespaces | |
| tsm | |
Macros | |
| #define | TSM_TICK_REP std::uint32_t |
| #define | TSM_TICK_PERIOD std::ratio<1> |
Typedefs | |
| using | tsm::tick_rep = TSM_TICK_REP |
| using | tsm::tick_period = TSM_TICK_PERIOD |
| using | tsm::tick_duration = std::chrono::duration< tick_rep, tick_period > |
| Chrono duration type used for semantic scheduler ticks. More... | |
Functions | |
| consteval tick_count | tsm::operator""_ticks (unsigned long long value) |
| constexpr tick_count | tsm::ticks (tick_rep value) noexcept |
| template<typename Rep , typename Period > | |
| constexpr tick_count | tsm::ticks (std::chrono::duration< Rep, Period > value) noexcept |
Detailed Description
Target-neutral tick value type.
A tick is the runtime's semantic time quantum. Platform code decides whether one tick represents 1 ms, 1 s, a SysTick interrupt, a FreeRTOS tick, or a simulated host interval. HSM and task code receives only this explicit count.
Macro Definition Documentation
◆ TSM_TICK_PERIOD
| #define TSM_TICK_PERIOD std::ratio<1> |
◆ TSM_TICK_REP
| #define TSM_TICK_REP std::uint32_t |
