runtime.h File Reference
Convenience include for runtime queue, executor, and topology APIs. More...
#include "tsm/runtime/actor.h"#include "tsm/runtime/app.h"#include "tsm/runtime/concepts.h"#include "tsm/runtime/coroutine.h"#include "tsm/runtime/executor.h"#include "tsm/runtime/policy.h"#include "tsm/runtime/resource_manifest.h"#include "tsm/runtime/resources.h"#include "tsm/runtime/runtime.h"#include "tsm/runtime/static_ring.h"#include "tsm/runtime/sync.h"
Include dependency graph for runtime.h:
This graph shows which files directly or indirectly include this file:
Go to the source code of this file.
Namespaces | |
| tsm | |
Typedefs | |
| template<typename Definition , typename Policy , template< typename > class MachinePolicy = runtime::detail::default_machine_policy> | |
| using | tsm::Runtime = runtime::Runtime< Definition, Policy, MachinePolicy > |
| template<typename Definition , typename Policy , template< typename > class MachinePolicy = runtime::detail::default_machine_policy> | |
| using | tsm::runtime_for = Runtime< Definition, Policy, MachinePolicy > |
| template<typename Runtime , std::size_t Capacity = 16U> | |
| using | tsm::delayed_event_timer = runtime::delayed_event_timer< Runtime, Capacity > |
| template<std::size_t Capacity> | |
| using | tsm::timer_queue = runtime::timer_queue< Capacity > |
| using | tsm::inline_executor = runtime::inline_executor |
| using | tsm::resource_budget = runtime::resource_budget |
| using | tsm::resource_snapshot = runtime::resource_snapshot |
| template<typename Runtime > | |
| using | tsm::task_resources = runtime::task_resources< Runtime > |
| template<typename Runtime , std::size_t TimerSlots = 0U, typename... Groups> | |
| using | tsm::runtime_resources = runtime::runtime_resources< Runtime, TimerSlots, Groups... > |
| template<typename Runtime , resource_budget Budget, std::size_t TimerSlots = 0U, typename... Groups> | |
| using | tsm::resource_contract = runtime::resource_contract< Runtime, Budget, TimerSlots, Groups... > |
| template<typename Profile , typename Runtime , std::size_t TimerSlots = 0U, typename... Groups> | |
| using | tsm::profile_resource_contract = runtime::profile_resource_contract< Profile, Runtime, TimerSlots, Groups... > |
| template<typename Definition > | |
| using | tsm::direct_runtime = Runtime< Definition, runtime_policy< dispatch_model::direct, queue_policy< static_storage< 2 > >> > |
| template<typename Definition , std::size_t Capacity, typename Overflow = overflow::reject_newest> | |
| using | tsm::queued_runtime = Runtime< Definition, runtime_policy< dispatch_model::queued, queue_policy< target_storage< Capacity >, Overflow > >> |
| template<typename Definition , std::size_t Capacity, typename Overflow = overflow::reject_newest> | |
| using | tsm::per_region_runtime = Runtime< Definition, runtime_policy< dispatch_model::per_region_queued, queue_policy< target_storage< Capacity >, Overflow > >> |
Functions | |
| template<typename... Tasks> | |
| tsm::cooperative_executor (Tasks &...) -> cooperative_executor< Tasks... > | |
| template<typename... Tasks> | |
| tsm::priority_cooperative_executor (Tasks &...) -> priority_cooperative_executor< Tasks... > | |
| template<typename... Runtimes> | |
| tsm::runtime_group (Runtimes &...) -> runtime_group< Runtimes... > | |
| template<typename... Actors> | |
| tsm::actor_group (Actors &...) -> actor_group< Actors... > | |
| template<typename Runtime > | |
| tsm::tick_executor (Runtime &) -> tick_executor< Runtime > | |
Detailed Description
Convenience include for runtime queue, executor, and topology APIs.
Includes runtime concepts, policy tags, fixed storage, executors, and runtime implementations.
Application and integration code can use this as the complete runtime surface. The runtime layer moves typed events, owns bounded queues, runs cooperative tasks, and advances explicit tick timers.
