coroutine.h File Reference

Static coroutine tasks for tsm runtime executors. More...

#include <array>
#include <concepts>
#include <coroutine>
#include <cstddef>
#include <cstdint>
#include <tuple>
#include <type_traits>
#include <utility>
#include "tsm/ticks.h"

Include dependency graph for coroutine.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
class	tsm::task
class	tsm::static_coroutine_arena< Bytes >
class	tsm::task_context
struct	tsm::task::promise_type
struct	tsm::task::promise_type::final_awaitable
struct	tsm::yield_awaitable
struct	tsm::sleep_ticks_awaitable
class	tsm::periodic_ticks
struct	tsm::timeout_ticks_awaitable
struct	tsm::select_result
	Result of a select wait. More...
class	tsm::select_awaitable< Awaitables >
class	tsm::send_event_awaitable< Runtime, Event >
class	tsm::checked_send_event_awaitable< Runtime, Event >
class	tsm::until_active_awaitable< State, Machine >
struct	tsm::instances< Count >
struct	tsm::frame_bytes< Bytes >
struct	tsm::task_priority< Priority >
struct	tsm::dynamic_task_slots< Count, FrameBytes >
struct	tsm::task_group< Entries >
struct	tsm::task_def< Entry, Options >
struct	tsm::tasks< TaskDefinitions >

Namespaces
	tsm
	tsm::runtime
	tsm::runtime::detail

Typedefs
using	tsm::every_ticks = periodic_ticks
template<typename Runtime >
using	tsm::runtime::detail::coroutine_scheduler_for = coroutine_scheduler< Runtime, typename runtime_task_list_of< Runtime >::type >
template<typename Runtime >
using	tsm::runtime::detail::priority_coroutine_scheduler_for = coroutine_scheduler< Runtime, typename runtime_task_list_of< Runtime >::type, true >
template<typename Runtime >
using	tsm::runtime::detail::executor_task_binding = basic_executor_task_binding< Runtime, coroutine_scheduler_for >
template<typename Runtime >
using	tsm::runtime::detail::priority_executor_task_binding = basic_executor_task_binding< Runtime, priority_coroutine_scheduler_for >
template<std::size_t Capacity>
using	tsm::runtime::timer_queue = detail::timer_queue< Capacity >
template<typename Runtime >
using	tsm::runtime::task_resources = detail::task_resources< Runtime >

Enumerations
enum class	tsm::task_wait_kind : unsigned char {   tsm::ready , tsm::running , tsm::sleeping , tsm::predicate ,   tsm::completed , tsm::failed }
enum class	tsm::task_status : unsigned char {   tsm::not_started , tsm::ready , tsm::running , tsm::waiting ,   tsm::completed , tsm::failed }
enum class	tsm::task_failure_reason : unsigned char {   tsm::none , tsm::allocation_failed , tsm::frame_too_large , tsm::wait_queue_full ,   tsm::timer_queue_full , tsm::cancelled , tsm::unhandled_exception }
enum class	tsm::spawn_result : unsigned char {   tsm::started , tsm::no_slot , tsm::frame_too_large , tsm::allocation_failed ,   tsm::invalid_entry }

Functions
task_context *	tsm::runtime::detail::find_task_context () noexcept
template<typename First , typename... Rest>
task_context *	tsm::runtime::detail::find_task_context (First &first, Rest &... rest) noexcept
yield_awaitable	tsm::yield () noexcept
sleep_ticks_awaitable	tsm::sleep_ticks (tsm::tick_rep ticks) noexcept
sleep_ticks_awaitable	tsm::sleep_ticks (tick_count ticks) noexcept
sleep_ticks_awaitable	tsm::after_ticks (tsm::tick_rep ticks) noexcept
sleep_ticks_awaitable	tsm::after_ticks (tick_count ticks) noexcept
timeout_ticks_awaitable	tsm::timeout_ticks (tsm::tick_rep ticks) noexcept
timeout_ticks_awaitable	tsm::timeout_ticks (tick_count ticks) noexcept
template<typename Awaitable >
void	tsm::runtime::detail::cancel_awaitable (Awaitable &awaitable, task_context &context) noexcept
template<typename... Awaitables>
auto	tsm::select (Awaitables &&... awaitables)
template<typename Awaitable >
auto	tsm::with_timeout (Awaitable &&awaitable, tsm::tick_rep ticks)
template<typename Awaitable >
auto	tsm::with_timeout (Awaitable &&awaitable, tick_count ticks)
template<typename Runtime , typename Event >
auto	tsm::send_event (Runtime &runtime, Event &&event)
template<typename Event , typename Runtime , typename... Args>
auto	tsm::send (Runtime &runtime, Args &&... args)
template<typename Runtime , typename Event >
auto	tsm::try_send_event (Runtime &runtime, Event &&event)
template<typename Event , typename Runtime , typename... Args>
auto	tsm::try_send (Runtime &runtime, Args &&... args)
template<typename State , typename Machine >
auto	tsm::until_active (Machine &machine) noexcept
consteval std::size_t	tsm::runtime::detail::selected_instances ()
template<std::size_t Count, typename... Rest>
consteval std::size_t	tsm::runtime::detail::selected_instances (tsm::instances< Count >, Rest...)
template<typename First , typename... Rest>
consteval std::size_t	tsm::runtime::detail::selected_instances (First, Rest... rest)
consteval std::size_t	tsm::runtime::detail::selected_frame_bytes ()
template<std::size_t Bytes, typename... Rest>
consteval std::size_t	tsm::runtime::detail::selected_frame_bytes (tsm::frame_bytes< Bytes >, Rest...)
template<typename First , typename... Rest>
consteval std::size_t	tsm::runtime::detail::selected_frame_bytes (First, Rest... rest)
consteval std::uint8_t	tsm::runtime::detail::selected_priority ()
template<std::uint8_t Priority, typename... Rest>
consteval std::uint8_t	tsm::runtime::detail::selected_priority (tsm::task_priority< Priority >, Rest...)
template<typename First , typename... Rest>
consteval std::uint8_t	tsm::runtime::detail::selected_priority (First, Rest... rest)

Variables
template<typename Awaitable >
concept	tsm::runtime::detail::basic_awaitable
template<typename Definition >
concept	tsm::runtime::detail::declared_task_definition
template<typename Definition >
concept	tsm::runtime::detail::dynamic_task_definition
template<auto Left, auto Right>
concept	tsm::runtime::detail::same_task_entry

Detailed Description

Static coroutine tasks for tsm runtime executors.

Coroutine tasks describe application workflows that run beside an HSM runtime: "do this later", "wait for this condition", and "run this cooperative loop" without adding OS threads, heap allocation, or callback registration to state-machine definitions.

Use this when behavior needs a small cooperative workflow beside event dispatch: startup sequences, periodic service loops, deferred retries, or tests that wait on runtime state. Tasks can send typed events, yield, sleep for explicit tick counts, and wait for machine conditions; transitions still happen only when events are dispatched through the runtime.
